RX2460A

Continuous SPL@1m: 149dBA，Notification Radius: 1761m
Maximum single-unit coverage area 9.74km² for cross-valley and cross-sea archipelagos.
Peak 155dBA sound pressure minimizes long-distance sound loss over sea and wilderness.
Three core broadcast functions: coastal defense live voice, disaster recording, bird repellent.
250Hz–7000Hz full-frequency unit for mass alert and full-range airport bird control.
Multi-level TCP/IP network supports provincial, municipal and county hierarchical management.
MIL-STD-810H certified + IP65 sealing for long service life on salt-fog islands.
Reserved multi-group dry contacts for customized large coastal defense & airport projects.

Quantity:
Availability:





Inquire Add to Basket

Product Description

FAQ

Application

Download

Product Overview

The RX2460A belongs to the flagship ultra-long-range omnidirectional acoustic warning series. It delivers an effective warning radius of 1782 meters, covering a total notification zone of 9.97 km². Designed for super-large-scale emergency broadcasting and hazard alert dispatch work, this unit fits extreme working environments such as remote archipelagos, virgin woodland zones, vast grasslands and major international airport zones. Equipped with standard TCP/IP network access ports, it facilitates cloud remote supervision, perfectly matching full-coverage mass notification system deployment requirements.

Description of Characteristics

• Boundless circular sound broadcasting coverage

It creates uninterrupted 360-degree horizontal sound diffusion without any geographic blind spots. The peak sound pressure reaches 156 dBA tested at one meter distance, forming a functional warning radius of 1782 meters and a total coverage area of 9.97 km² to accomplish seamless wide-area acoustic signal coverage.

• Multi-format flexible audio operational compatibility

Operators conduct instant live voice paging through external microphones. The hardware decodes mainstream audio files including MP3, AAC and WAV formats, retains local built-in playback and recording storage functions, and recognizes media files loaded from USB flash drives and TF memory storage cards.

• Premium voice intelligibility and authentic sound restoration

Its tuned frequency response spectrum ranges from 250Hz to 7000Hz. This bandwidth precisely fits human speech frequency bands, wild bird vocalization and various wildlife audio waveforms, making it ideal for site public announcements, tiered emergency alert broadcasts, large-range bird repelling and organized crowd evacuation guidance tasks.

• Diversified deployment modes and centralized systematic control

Preinstalled with standard TCP/IP communication interfaces, administrators can execute remote operations via professional control terminals. The hardware supports seamless docking with customized security monitoring platforms and multi-level command dispatch systems to realize unified centralized asset management.

• Top-tier military-grade harsh environment endurance

The whole unit passes full-condition verification under the MIL-STD-810H military testing standard, covering high and low temperature alternation, thermal humidity circulation, sandstorm erosion, rain immersion, salt spray corrosion and structural vibration impact. Rated at IP65 ingress protection, the equipment maintains steady running performance under continuously volatile extreme climatic surroundings.

• Ultra-wide global voltage adaptive capability

Matched with an exclusive dedicated power distribution cabinet, the device accepts 110V to 260V full-range AC input. It adapts to grid standards across every region worldwide, and can coordinate with customized solar power storage systems to guarantee non-stop stable operation in off-grid remote wilderness territories with fluctuating power supply conditions.

Table of Key Equipment Parameters

Parameter	Details
Peak SPL@1m	155dBA
Continuous SPL@1m	149dBA
Continuous SPL@30m	119dBA
Notification Radius	1761m
Notification Area	9.74km²
Dimension(D*H)	700mm*2380mm
Weight	157kg
IP Rating	IP65

FAQ

What installation methods does this product support?

The RX2460A adopts permanent fixed installation schemes, suitable for mounting on barrier-free elevated structures including signal transmission towers, overhead utility poles, mountain ridge platforms and large reservoir dam constructions.

In what environments can this product be used?

With an operational temperature scope of -40°C to +50°C alongside IP65 protection grade and upgraded anti-corrosion salt spray structure, this flagship device works reliably on offshore wind farm platforms, remote isolated islands, alpine tundra, desert wastelands and ultra-high altitude plateau regions throughout all seasons.

Does it support a dry contact interface?

The RX2460A reserves standard dry contact signal ports, enabling quick linkage triggering with peripheral alarm sensors and perimeter defense systems.

Is an electrical cabinet supported?

A customized professional power control cabinet is delivered as standard configuration, supporting long-duration stable operation and integrated scheduling for large-scale regional emergency warning networks.

What are the control methods for this product?

Relying on the TCP/IP communication protocol framework, available operation channels contain wired desktop controllers and portable handheld tablet devices. Enterprises can also embed the equipment into internal command scheduling systems to achieve synchronized linkage management across multiple device terminals.

Does this product support 4G or 5G remote control?

Extended communication slots are reserved by default, allowing optional hardware upgrades with 4G, 5G and long-distance wireless transmission modules to achieve cellular-network-based off-site remote control management.

Does this product support solar panel power?

Complete solar photovoltaic power supply solutions are available for custom configuration. Our technical team will calculate photovoltaic panel size and matching battery capacity according to local sunshine duration, to sustain reliable equipment operation within fully off-grid regions.

Does this product support OEM/ODM customization?

Full-scale OEM and ODM personalized customization services are available. Adjustable customization items include system display languages, outer casing paint colors and printed equipment identification nameplates. Customized development covers premium functional modules, such as high-brightness LED warning beacons, one-click emergency shortcut buttons, multilingual pre-recorded warning sentence translation packages, and exclusive customized operating interface layouts.

Application

The RX2460A is developed specifically for large-scale cross-region mass notification engineering projects. Possessing the strongest acoustic output and maximum coverage range within the whole product lineup, this flagship unit undertakes perimeter intrusion alert triggering, wide-area broadcast notice distribution, cross-regional disaster graded early warning release, and large-scale crowd evacuation guidance. It serves as core hardware for typhoon prevention early warning networks, tsunami safety monitoring systems and full-area mountain forest fire prevention broadcast frameworks.
